Дънна платка Asrock B450 Steel Legend

Статус :В наличност

Категория:Дънни платки

219.00 лв

Описание

Дънните платки ASRock дават невероятна производителност и превъзходна естетика, за да управляват вашия собствен цветен начин на осветление! ASRock предлага много изчерпателен контрол за изпълнение на вградените RGB светодиоди или свързаните LED ленти, CPU вентилатори, охладители, шасита и всички RGB устройства. Тази дънна платка има двойка вградени Тип-A и Тип- C USB 3.1 Gen2 портове, изградени върху задната част I / O за подпомагане на следващото поколение USB 3.1 Gen2 устройства и за 10 Gbps скорост на трансфер на данни.

Серия	Steel Legend
Процесор	AMD AM4
Чипсет	AMD Promontory B450
BIOS	128Mb AMI UEFI Legal BIOS with multilingual GUI support, Supports "Plug and Play", ACPI 5.1 compliance wake up events, Supports jumperfree, SMBIOS 2.3 support, DRAM Voltage multi-adjustment
Памет, слотове	4 x DDR4 DIMM Slots, Max. capacity of system memory: 64GB, Dual Channel DDR4 Memory Technology
Аудио	7.1 CH HD Audio with Content Protection, Premium Blu-ray Audio support, Supports Surge Protection, Nichicon Fine Gold Series Audio Caps, PCB Isolate Shielding, Individual PCB Layers for R/L Audio Channel, Gold Audio Jacks
Мрежа	PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111H, Supports Wake-On-LAN, Supports Lightning/ESD Protection, Supports Energy Efficient Ethernet 802.3az, Supports PXE
Безжична мрежа	-
Конектори	1 x COM Port Header, 1 x TPM Header, 1 x Power LED and Speaker Header, 1 x RGB LED Header, 2 x USB 2.0 Headers, 1 x USB 3.1 Gen1 Header, 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 1 x Front Panel Audio Connector
Слотове	AMD Ryzen series CPUs (Matisse, Summit Ridge and Pinnacle Ridge): 2 x PCI Express 3.0 x16 Slots; AMD Ryzen series CPUs (Picasso, Raven Ridge): 2 x PCI Express 3.0 x16 Slots; AMD Athlon series CPUs: 2 x PCI Express 3.0 x16 Slots; 4 x PCI Express 2.0 x1 Slo
M.2 слот	1xUltra M.2 (M2_1), supports M Key type 2230/2242/2260/2280 M.2 PCI Express up to Gen3 x4 (32 Gb/s) or Gen3 x2 (16 Gb/s); 1xM.2 (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s and M.2 PCI Express up to Gen3 x2 (16 Gb/s)
Интерфейс	1 x PS/2 Mouse/Keyboard Port, 1 x HDMI Port, 1 x DisplayPort 1.2, 1 x Optical SPDIF Out Port, 2 x USB 2.0 Ports, 1 x USB 3.1 Gen2 Type-A Port, 1 x USB 3.1 Gen2 Type-C Port, 4 x USB 3.1 Gen1 Ports, 1 x RJ-45 LAN Port with LED, HD Audio Jacks
Софтуер	ASRock A-Tuning, ASRock Polychrome SYNC, ASRock XFast LAN
Операционна система	Microsoft Windows 10 64-bit
Форм-фактор	ATX
Специални функции	ASRock USB 3.1 Gen2, ASRock Super Alloy, ASRock Steel Slot, ASRock Full Coverage M.2 Heatsink, ASRock Ultra M.2, ASRock Ultra USB Power, ASRock Full Spike Protection, ASRock Live Update & APP Shop, AMD StoreMI
Гаранция	36 месеца

Серия	Steel Legend
Процесор	AMD AM4
Чипсет	AMD Promontory B450
BIOS	128Mb AMI UEFI Legal BIOS with multilingual GUI support, Supports "Plug and Play", ACPI 5.1 compliance wake up events, Supports jumperfree, SMBIOS 2.3 support, DRAM Voltage multi-adjustment
Памет, слотове	4 x DDR4 DIMM Slots, Max. capacity of system memory: 64GB, Dual Channel DDR4 Memory Technology
Аудио	7.1 CH HD Audio with Content Protection, Premium Blu-ray Audio support, Supports Surge Protection, Nichicon Fine Gold Series Audio Caps, PCB Isolate Shielding, Individual PCB Layers for R/L Audio Channel, Gold Audio Jacks
Мрежа	PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111H, Supports Wake-On-LAN, Supports Lightning/ESD Protection, Supports Energy Efficient Ethernet 802.3az, Supports PXE
Безжична мрежа	-
Конектори	1 x COM Port Header, 1 x TPM Header, 1 x Power LED and Speaker Header, 1 x RGB LED Header, 2 x USB 2.0 Headers, 1 x USB 3.1 Gen1 Header, 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 1 x Front Panel Audio Connector
Слотове	AMD Ryzen series CPUs (Matisse, Summit Ridge and Pinnacle Ridge): 2 x PCI Express 3.0 x16 Slots; AMD Ryzen series CPUs (Picasso, Raven Ridge): 2 x PCI Express 3.0 x16 Slots; AMD Athlon series CPUs: 2 x PCI Express 3.0 x16 Slots; 4 x PCI Express 2.0 x1 Slo
M.2 слот	1xUltra M.2 (M2_1), supports M Key type 2230/2242/2260/2280 M.2 PCI Express up to Gen3 x4 (32 Gb/s) or Gen3 x2 (16 Gb/s); 1xM.2 (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s and M.2 PCI Express up to Gen3 x2 (16 Gb/s)
Интерфейс	1 x PS/2 Mouse/Keyboard Port, 1 x HDMI Port, 1 x DisplayPort 1.2, 1 x Optical SPDIF Out Port, 2 x USB 2.0 Ports, 1 x USB 3.1 Gen2 Type-A Port, 1 x USB 3.1 Gen2 Type-C Port, 4 x USB 3.1 Gen1 Ports, 1 x RJ-45 LAN Port with LED, HD Audio Jacks
Софтуер	ASRock A-Tuning, ASRock Polychrome SYNC, ASRock XFast LAN
Операционна система	Microsoft Windows 10 64-bit
Форм-фактор	ATX
Специални функции	ASRock USB 3.1 Gen2, ASRock Super Alloy, ASRock Steel Slot, ASRock Full Coverage M.2 Heatsink, ASRock Ultra M.2, ASRock Ultra USB Power, ASRock Full Spike Protection, ASRock Live Update & APP Shop, AMD StoreMI
Гаранция	36 месеца
